SJD 6 D-handle orbital jig saw

Choose options

Pack size

1 pc

Product options

Quantity

Packs

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Discounted net

From SGD 639.00

Technical Data

Rated input power

850 W

Handle

Hoop grip

Weight according to EPTA-Procedure 01/2003 without battery

2.4 kg

Base material

Aluminium, Drywall, Gypsum board, Hardwood (beech, oak etc.), Non-ferrous metal, Plastic, Plywood, Wood, Wood composites, Tiles

Stroke length

28 mm

Stroke rate

3000 strokes/minute

Max. bevel angle

45 °

Max. cutting depth in mild steel

10 mm

Max. cutting depth for wood

150 mm

A-weighted emission sound pressure level

93 dB (A) ¹

Triaxial vibration value for cutting board (ah,B)

9.7 m/s² ²

Uncertainty (K) for triaxial vibration value for cutting board (ah,B)

1.5 m/s² ³

Triaxial vibration value for cutting sheet metal (ah,M)

8.0 m/s² ⁴

Uncertainty (K) for triaxial vibration value for sawing in metal (ah)

1.5 m/s² ⁵

According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)

Documents

pdf Operating Instruction SJD 6, Arabic, Bulgarian, cn, Czech, Danish, German, Greek, English, Spanish, Estonian, Finnish, French, Hebrew, Croatian, Hungarian, Italian, Japanese, Kazakh, Korean, Lithuanian, Latvian, Malay, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Sardinian, Slovak, Slovenian, Swedish, Thai, Turkish, Ukrainian, Vietnamese, Chinese, Serbian [ 3.9 MB ]

Download

Features & Applications

Features

Upgraded ergonomics with large baseplate – this lighter and more compact D-handle jig saw improves your manoeuvrability, stability and cut precision
850W motor – delivers the cutting power you need to slice through tougher boards and metal
Keyless blade change – minimise your downtime while replacing jig saw blades
Virtually dust-free sawing – this jig saw has a dust blower and extraction adapter, keeping your cutting line clear
Speed dial and adjustable pendulum stroke – the operator has precise control over how fast the orbital jig saw cuts and how clean the final result needs to be

Applications

Trimming or cutting wood and plasterboard to size with minimal airborne sawdust when using DRS
Interior finishing – especially sawing plasterboard or wood-based internal cladding (horizontal or vertical cuts)
Cutting wood board up to 150 mm thick
Cutting metal sheet up to 10 mm thick
Cutting tiles and plastic pipes

For approval or certificate information, please see individual items.
