HDA-PF Undercut anchor
Ultimate-performance pre-set undercut anchor for dynamic loads (sherardised steel)
- Material, corrosion: Carbon steel, HDG (hot-dip galvanised)/sherardised
- Head configuration: Externally threaded
- PROFIS software: No
Choose options
Anchor size
- M10
- M12
- M16
Standard embedment depth
- 100 mm
- 125 mm
- 190 mm
Max. fixture thickness at standard embedment depth
- 20 mm
- 30 mm
- 40 mm
- 50 mm
- 60 mm
Pack size
- 4 pc
- 8 pc
- 12 pc
Quantity
Packs
Total Pieces
1
Discounted net
From SGD 720.00
Technical Data
Material, corrosion
Carbon steel, HDG (hot-dip galvanised)/sherardised
Head configuration
Externally threaded
PROFIS software
No
Type of fastening
Pre-fastening
Documents
Features & Applications
Features
- Combines the advantages of a post-installed mechanical anchor, i.e. flexibility and immediate loading, with the performance of a cast-in-place headed stud
- Close spacing and small edge distances thanks to very low expansion forces
- Self-undercutting facilitates fast and reliable installation – no separate undercutting tool or handling needed
- The resulting keying effect helps provides a secure hold even in cracked concrete
- Manufactured under the NQA-1 nuclear quality assurance program
Applications
- Safety-relevant, heavy-duty fastenings for dynamic loading in cracked or uncracked concrete, including applications in nuclear power plants
- Examples: supports for heavy pipes, safety barriers, industrial machines, crane rails, dorm structures, crash barriers, roof fastening points, elevator tracks, bridge retrofitting etc.
For approval or certificate information, please see individual items.
