HIT-HY 270 Adhesive anchor

Hilti HIT-HY 270 – PROFIS design in masonry

HIT-HY 270 – fastening in masonry with the HDE dispenser.

Ultimate-performance injectable hybrid mortar with approvals for fastening and retrofitting in hollow and solid masonry

Base materials: Masonry (hollow), Masonry (solid)
Base material condition: Dry, Wet
Approvals / test reports: ETA

Customers also searched for injectable adhesive anchor, hybrid mortar for masonry, chemical anchor, heavy duty anchor or post installed.

Technical Data

Base materials

Masonry (hollow), Masonry (solid)

Base material condition

Dry, Wet

Approvals / test reports

ETA

PROFIS software

Yes

Anchoring elements

AM rods, HIT-SC mesh sleeves, HIT-V threaded rods

Environmental conditions

Dry indoor, Indoor with temporary condensation, Outdoor (more than 1km to coast)

Cleaning procedures

Manual cleaning

Storage and transportation temperature range

5 - 25 °C

In-service temperature – range

-40 - 80 °C

Free of styrene

Yes

Documents

Features & Applications

Features

Seismic ETA masonry approval, new TR053 and technical data available – significantly increases your flexibility when designing steel-to-masonry connections
Simplify code-compliant design – design fastenings in masonry, including under seismic loads, with greater speed and ease using the PROFIS Engineering software suite
Compatible with HIT-SC composite sleeves for use in hollow base materials – offering greater flexibility through use of multiple sleeve combinations and also minimising mortar waste by allowing more accurate dosing
On-site anchor testing available – request Hilti’s on-site anchor testing service for verification of both tensile and shear loads in both horizontal and vertical directions

Applications

Fastening structural steel to hollow and solid masonry
Cost-effective seismic retrofitting and structural strengthening of old masonry walls
Refurbishment and renovations of older masonry buildings
Heavy bracing of items such as sunshades on insulated materials
Fastening glass balustrade assemblies

For approval or certificate information, please see individual items.
