HIT-RE 500 V4 Epoxy anchor

Ultimate-performance injectable epoxy mortar with approvals for rebar connections and heavy-duty anchoring

  • Base materials: Concrete (cracked), Wood
  • Base material condition: Dry, Submerged, Water-filled, Wet
  • Approvals / test reports: BZS/shock, ETA, Fire, Seismic

Technical Data

Base materials
Concrete (cracked), Wood
Base material condition
Dry, Submerged, Water-filled, Wet
Approvals / test reports
BZS/shock, ETA, Fire, Seismic
Seismic loading
Yes
Fatigue loading
Yes
Fire resistance
Yes
PROFIS software
Yes
Anchoring elements
HAS-U threaded rods, HIS-N internally threaded sleeves, Rebar
Environmental conditions
Outdoor
Cleaning procedures
Automatic cleaning (SafeSet hollow drill bit), Compressed-air cleaning, Manual cleaning
Storage and transportation temperature range
5 - 25 °C
In-service temperature – range
-40 - 75 °C
Free of styrene
Yes

Documents

Features & Applications

Features

  • Ultimate performance and model code-compliant design for virtually any concrete-to-concrete and steel-to-concrete connections – ETA assessment for anchoring inc. C1 and C2 seismic and ETA for rebar inc. fire and seismic
  • The first epoxy mortar qualified according to EAD 332402-00-0601 for concrete-to-concrete connections – rigid connections can now be designed and executed with post-installed rebars without splices according to the newest design method TR069
  • Suitable for the toughest jobsite conditions – works even in diamond-cored, wet or underwater holes (depending on rod specification and approvals), extremely deep injections, large diameters and at temperatures down to -5°C / 23°F
  • Improved bond strength in the most demanding applications – such as cracked concrete and seismic C2 conditions
  • Easier to specify and order – use PROFIS Engineering to design baseplate connections and PROFIS Rebar to design concrete-to-concrete connections according to EC2, TR069 or the Hilti Design Method

Applications

  • Structural connections with post-installed rebar (e.g. slab extensions, wall/column connections, stairs, foundations, etc.)
  • Structural renovation of buildings, bridges and other civil works, retrofitting and re-strengthening of concrete members
  • Anchoring structural steel connections (e.g. steel columns, beams, etc.)
  • Fastening structural baseplates, including in cracked concrete and challenging seismic conditions
  • Fastening in natural stone and wood, including GLT and CLT made from spruce, pine or fir

For approval or certificate information, please see individual items.
