PROFIS Engineering Suite is cloud-based, so you can get started instantly. Even the latest codes and product details update automatically. All this pre-set information can save you hours researching the latest approvals, codes and anchors. Avoid other slow, error-prone tasks – like manual load transfer – thanks to the direct import function from other structural analysis software such as Etabs, Robot, SAP2000, StaadPro, Dlubal RFEM and RSTAB.
The extra precision offered by the paid version of PROFIS Engineering Suite, especially Component-based Finite Element Method (CBFEM) analysis, helps you cut excessive tolerances when designing connections. The result is a design which helps you to save material and labor costs, while still reflecting relevant codes and real behavior of the whole baseplate connection.
After the free trial of the premium version ends, you can still rely on PROFIS Engineering Suite for virtually all common structural connections. Our standard free software is ideal for everyday cases where rigid design or a baseplate rigidity check is enough. You will be able to design cast-in place anchors using the free software.
Detailed, step-by-step anchor design reports displaying drawing and structural formulas on each step can be generated on-demand. Your designs can also be exported in 2D and 3D for integration into your standard BIM and CAD programs.
Various Eurocodes, ACI, AISC, Indian Standards, Australian Standards and Russian Codes are supported. PROFIS Engineering Suite automatically updates to use the latest versions of the codes and approvals you need.
Designing with PROFIS Engineering Suite can improve efficiency on the jobsite too. Site Managers can use our smartphone app to find anchor item numbers, while Contractors can easily generate handrail reports to satisfy EN 1090 quality and safety standards.
PROFIS Engineering is a cloud-based software to design steel-to-concrete and concrete-to-concrete connections according to a wide range of codes and approvals.
PROFIS Engineering can now calculate and analyse multiple fixings such as steel-to-concrete and concrete-to-concrete to be cost-effective and code-compliant. It also comes with application-specific engineering training to support you.
Perform steel-to-concrete and concrete-to-concrete calculations to reduce error and rework.
Design your connections according to local regulations.
Integrated data sharing grants access to the most up-to-date design files and reports.
Use preset templates to design concrete fixings including post-installed and cast-in-place anchors, baseplates, welds and stiffeners quickly and accurately. With just a click you can analyze baseplates using the Component-based Finite Element Method (CBFEM) and perform rigidity checks to determine whether to adapt the design or the loads. Optimize fixture points and perform stress and strain checks – PROFIS considers applied loads such as seismic and fatigue to find the best solution. Smart baseplate design further simplifies your design process.
Generate a customized report complete with code references, calculations, product information and images.
Add or extend concrete elements whether you're working with existing rebar or missing starter bars. Solve concrete structural joints and splices and then verify the shear resistance at the interface between the old and new concrete.
Need to adapt the layout or geometry of your PIR design? PROFIS lets you easily customize the diameter, embedment depth and spacing parameters for existing concrete as well as post-installed.
With PROFIS, you can design post-installed shear connectors and verify the interface between the concrete cast at different times. Establish whether your design has edges or is symmetric, and then define different areas of acting shear. You'll know your designs are sound thanks to intuitive 3D graphics that show how stresses vary throughout the connection.
Ready for installation? PROFIS has already saved you time by optimizing the layout.
