TE 30-ATC/AVR Rotary hammer

Powerful SDS Plus (TE-C) rotary hammer for heavy-duty concrete drilling and corrective chiselling, with Active Torque Control (ATC) and Active Vibration Reduction (AVR)

Weight according to EPTA-Procedure 01/2003 without battery: 4 kg
Optimum hammer drilling range: 10 - 20 mm
Single impact energy: 3.6 J

Customers also searched for Hammer, drill, combi, corded or light.

Technical Data

Weight according to EPTA-Procedure 01/2003 without battery

4 kg

Optimum hammer drilling range

10 - 20 mm

Single impact energy

3.6 J

Working mode

Hammer drilling, Chiselling, Chisel setting, Drilling

Hammer drilling diameter range

4 - 28 mm

Hammer drilling RPM

850 rpm

Full hammering frequency

4500 impacts/minute

Functionality

Active Torque Control (ATC), Active Vibration Reduction (AVR), Removable chuck, Reverse mode, Depth gauge

Triaxial vibration value for hammer drilling into concrete (ah,HD)

10 m/s² ¹

Triaxial vibration for chiselling in concrete

10.2 m/s² ²

A-weighted emission sound pressure level

91 dB (A) ³

Dimensions (LxWxH)

371 x 109 x 218 mm

According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see the Operating Instruction for more details)

Documents

Features & Applications

Features

Active Torque Control (ATC) stops the tool body from spinning uncontrolledly if the drill bit jams – helping to reduce a common safety hazard
Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
Brushless motor for exceptionally high performance and superior system efficiency
Quick-change chucks – changing bits is fast and tool-free
Extra-long lifetime thanks to a highly robust chuck, motor components and casing

Applications

Drilling anchor holes and through-holes in concrete and masonry, diameter range 4-28 mm, recommended range 10-20 mm
Drilling holes for rebar doweling, diameter range 4 - 28 mm, recommended range 10 - 20 mm
Corrective chiselling
Drilling in wood, metal and other materials using the quick-release chuck
Driving and removing screws using the quick-release chuck

For approval or certificate information, please see individual items.

Services

Hilti Tool Service

Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
Product warranty against parts and manufacturing irregularities for 20 years
After 2 years repair costs are capped
1-month no-cost period after each paid repair
Exclusive use of genuine Hilti spare parts

More information about Tool Services

Fleet Management

Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
High-performing tools and latest technology help to increase jobsite productivity.
Loan tools during repair to reduce downtime.
Temporary tools for peak times and special applications help to reduce investments.
Theft coverage helps to reduce financial risk and unexpected expenses.

More information about Fleet Management
